Android Smart Tablet OEM Custom Solutions Commercial

Shenzhen Zhiwei Technology CO., LTD designs this Android smart tablet for commercial projects.

You can deploy it in self-service ordering machines, video conferencing systems, smart blackboards,

self-service terminals, transportation and logistics sites, and advertising displays.

We combine a rugged touchscreen with flexible configurations, so the device fits retail,

office, and public facility projects with ease.

Clear Audio & Optional NFC Functions

The built-in microphone and speaker support smooth communication during video calls and kiosk interactions.

We offer optional NFC functions to expand its uses. Businesses often choose NFC for access control, attendance tracking,

and contactless payments. This feature simplifies daily operations and creates better user experiences for customers.

Easy Installation with Optional POE

We provide an optional POE power supply to simplify device setup. One Ethernet cable delivers both network data

and electric power. You can cut down wiring work and save installation costs, which makes this tablet a great

choice for large-scale digital signage and self-service terminal projects.

Customized Solutions for Different Applications

We adjust hardware and software settings according to your actual usage requirements. From logistics management

centers to smart classrooms and self-service kiosks, our Android tablet offers stable performance.

It helps your business build efficient, connected smart terminal systems.

System	CPU	RK3566/RK3568/RK3576/RK3588
	RAM	2GB/4GB
	Internal memory	32GB/64GB
	Operation system	Android 11
Display screen parameters	Panel Size	15.6-inch
	Back-light Type	LED
	Panel Type	IPS（NV156FHM-N22）
	Resolution	1920(RGB)×1080, FHD
	Aspect Ratio	16:9
	Refresh rate	60Hz
	Color Quantity	262K , 45% NTSC
	Viewing angle	85/85/85/85 (Typ.)(CR≥10)
	Pixel layout	RGB vertical stripe
	Contrast ratio	1200:1
	Optical mode	ADS， Constant black display, transmissive
	Response Time	5ms
	Luminance	300cd/m2
	Working Temperature	0 ~ 50 °C
	Storage Temperature	-20 ~ 60 °C
Touch optional	Touch type	Capacitive touch screen
	Number of points	10-Point
	Interface for touch	USB
Network	WiFi	IEEE 802.11b/g/n/a/ac
	Bluetooth	Bluetooth 5.4
	Ethernet	10M/100M/1000M
Media plays	Camera	300W/500W optional
	Video format	MPEG-1,MPEG-2,MPEG-4,H.265,H.264,H.263,VC-1,VP8,VP9,MVC, etc.support up to 4K
	Audio format	MP3/WMA/AAC/WAV/OGG, etc
	Photo	JPEG/PNG/GIF,etc
Other	Button	Power
	G-sensor	Support
	Speaker	4Ω3W2
	Microphone	Standard Quad Microphone , Support noise reduction and echo cancellation
	NFC (optional, not included in standard quotation)	Optional , 13.56MHz，ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A&B, ISO/IEC 15693, Japanese Industrial Standard (JIS) (X) 6319-4, MIFARE Classic encrypted tags and cards
	Camera	5.0MP Camera
	Language	Multi-language
	Certificate (certified adapter	CE/ROHS
	POE (optional, not included in standard quotation)	Optional （IEEE802.3at, up to 30W )
Interface	Power Jack	DC 12V (outer diameter 6.0mm, inner diameter 2.0mm DC socket)
	Type-C	1 (Standard USB 3.0 Type-C interface, fixed USB OTG mode, can be set to USB Host mode, current limit 1.5A)
	USB3.0	1 (Standard USB 3.0 Type-A interface, fixed Host mode, current limiting 1.5A)
	USB2.0	2 (Standard USB 2.0 Type-A interface, fixed Host mode, current limiting 1.5A)
	RJ45	1 (10/100M Ethernet interface, expandable POE power supply)
	HDMI	1 (Standard HDMI Type-A interface, HDMI 2.0 output display, maximum support) 4K@60Hz )
	headphone output	1 (Standard 3.5mm, 4-section headphone jack)
	SIM	1 (Nano SIM card holder, with card holder, can be connected to different telecom operators’ nano SIM cards, and can also be connected to 4G modules and antennas)
Standard List	The power adapter		1 piece, specification: AC100-240V 50/60HZ 12V4
	power line		1 piece
	Instruction Manual		1 book1
